Achievements

“DTF Multi-function Turning Center”

Outside　Dimensions		A3 size
Lathe Turning Spindle		1 axis, BT5, 7000rpm, 200W, Stops at an arbitrary angle
Side milling spindle		1 axis, BT5, 7000rpm, 200W, Stops at an arbitrary angle
Number of Tools		3
Tool Exchanger		6 tools can be mounted
X axis (Longitudinal)		Stroke　50mm・50W
Y axis (Vertical)		Stroke 300mm・50W
Z axis (Lateral)		Stroke　50mm・50W

Outside dimensions		812×303×300(mm)
External Diameter of the Dram		150(mm)
Width of the Dram		12(mm)
Capacity of the Tank		1（L）×6
Heater Output		440（W）
Power supply		100（V）
Size of ｗorkpiece		φ2×10(mm)
Cycle Time		70s
